ADJUSTABLE HEIGHT TOWING COUPLINGS

"The Towbar you can adjust in seconds for the perfect towing set-up"

To tow any trailer in a safe and stable condition it is essential that the height of the vehicle's towball/jaw matches that of the trailer. Dixon-Bate Adjustable Height Towbars include a height adjustable coupling plate that provides the perfect solution.

The Standard Adjustable Height Towbar range includes three different length frames, each pre-drilled with a range of hole centres for fixing to a vehicle or existing towbar, and includes pin, slider, rclip and a selection of fixing bolts. There is also a 2 pin slider version which provides a good heigh range in a compact unit.

Each Adjustable Height Towing Coupling includes the following elements:

Defender 90 with Adjustable and Universal

For Pricing, Information, Fitting Instructions and to place an Enquiry Please Click the Product


Photo showing product features - see below for the products		MAIN FRAME One-piece fabricated steel framework includes back-plate for fixing to vehicle or towbar, and a parallel series of vertically spaced hales to secure the slider. Provides height adjustment from 3 to 6 positions (dependant on model) in 50mm increments.

		ADJUSTABLE SLIDER Pre-drilled with 4 holes to accept either towing couplings with 2 bolt fixing (BS Au 114a) or 4 bolt fixing (BS Au 24). These include towballs, universal couplings and jaws, plus NATO pintles. Fits all Dixon-Bate Adjustable Couplings and is available as a spare. Part No. 68036.
		PIN 19mm dia steel pin used to secure the slider to the main frame in the position required. Single pin permits full height adjustment to all positions on the frame. Part No 66702.
		RETAINING CLIP Used to secure the pin in place. Removable without the use of tools for quick and easy height adjustment. Part No. 102960.
		LOCK (OPTIONAL) Special pin and barrel lock for extra security. Secures slider to frame and requires key to release. Part No. 202018
		FINISH All Dixon-Bate Adjustable Couplings are finished in a black phosphate primer for corrosion resistance and black powder top-coat. Pins and clips are zinc phosphate bright finish.


200mm Height Adjustment Long Part No. 202090	150mm Height Adjustment Medium Part No. 202091	100mm Height Adjustment Short Part No. 202092	200mm Height Adjustment 2 pin Slider Part No. 202117

Multi-height adjustment - 3 to 6 positions in 50mm increments All Steel Construction Slider pre-drilled with 4 holes to accept towing couplings with either 2 hole fixing (BS Au 114a) or 4 hole fixing (BS Au24) Simple safe and secure locking mechanism Adjust the height without tools 19mm dia steel pin to secure the slider in place with R clip Optional Lock to secure slider to frame with key release All Dixon-Bate couplings are finished in a black phosphate primer for corrosion resistance and black powder top-coat. Pins and clips are zinc phosphate bright finish Range of height adjustable towbars available

To see the current range of Standard Towbars and Adjustable Brackets available for 4 x 4 and Light Commercial Vehicles,
please use the Bracket Selector.

We have a large range of accessories for use with the Adjustable Couplings
